Mounting bracket for fiber optic sensors

Fiber optic sensor mounting brackets are specialized hardware used to securely position and adjust fiber optic sensors, available in various materials, types, and configurations to suit different applications.

Fiber optic sensor brackets come in several configurations to accommodate different installation needs:

• Fixed Axial Brackets: Hold the sensor in a fixed position along a single axis. Ideal for straightforward installations where sensor alignment does not need adjustment .
• Right-Angle Brackets: Allow mounting at 90 degrees to the base surface, often with fine-tune adjustments for precise sensor positioning .
• Swivel or Ball-Joint Brackets: Enable multi-directional adjustment, allowing the sensor to be oriented accurately in tight or complex spaces .
• Combination or Stand-Type Brackets: Include a stand, pipe, and bracket as a set, providing a complete mounting solution .

Brackets are manufactured from a variety of materials depending on durability and environmental requirements:

• Aluminum: Lightweight and corrosion-resistant, suitable for general industrial use .
• Stainless Steel: Offers high strength and corrosion resistance, ideal for harsh environments .
• Resin or Plastic: Lightweight and non-conductive, often used in applications where metal interference must be minimized .
• Black Painted Finish: Recommended for light-based sensors to reduce reflections and improve measurement accuracy .

When selecting a bracket, it is important to:

• Match the bracket to the specific sensor model to ensure proper fit and secure mounting .
• Check for interference from connectors or other components that may obstruct the sensor .
• Refer to the sensor datasheet for manufacturer-recommended bracket types and materials .

• Mounting Rods: Available in lengths up to 500mm for installing swivel or adjustable brackets .
• Cleaning Options: Some brackets come pre-cleaned with degreasing, precision cleaning, or electrolytic polishing to reduce installation preparation time .
• CAD Models and Online Ordering: Many suppliers provide CAD downloads and online ordering for easy integration into design workflows .

Fiber optic sensor mounting brackets are essential for ensuring accurate sensor alignment, stability, and protection, and choosing the right type and material can significantly improve sensor performance and longevity .
