How to press down the small side of the cable tray

Fiber optic splice closure knowledge brief Published 01 Apr 2025

Prepared for preliminary research by the RIVO OPTICAL knowledge desk. Confirm cable count, splice capacity, sealing class, tray layout, protection sleeves and installation requirements against current standards and product documentation.

Use hand-operated clips, snap-on fasteners, or rivet buckles to securely press down the small side of a cable tray.Using Clips or Snap-On Fasteners

Many cable trays come with clips designed to lock the cover or side flange in place. These clips typically have a main body that fits inside the tray and a smaller part that grips the side or cover. To secure the small side:

  • Slide the clip onto the edge of the tray so that it clamps the side and cover together.
  • Apply firm hand pressure until the clip snaps into place.
  • Some models may include a screw for additional tightening if a more permanent hold is needed .
Using Rivet Buckles

For a semi-permanent installation, rivet buckles can be used:

  • Position the buckle over the tray edge and cover.
  • Use a rivet tool or screw to fasten it securely.
  • This method ensures a long-lasting, stable connection, ideal for areas with vibration or heavy traffic .
Tips for Safe and Effective Installation
  • Check tray type: Ladder, solid-bottom, or ventilated trays may require different clip designs .
  • Avoid over-bending: Pressing too hard can deform the tray or damage the coating.
  • Use gloves: Protect your hands from sharp edges while pressing or snapping clips.
  • Spacing: Place clips or buckles at regular intervals along the tray side to maintain uniform pressure and stability. By following these methods, the small side of the cable tray will be securely pressed down, ensuring proper cable containment and compliance with installation standards .
