Huijue Adding an Optical Module

Fiber optic splice closure knowledge brief Published 26 Dec 2023

Prepared for preliminary research by the RIVO OPTICAL knowledge desk. Confirm cable count, splice capacity, sealing class, tray layout, protection sleeves and installation requirements against current standards and product documentation.

To add a Huijue optical module, ensure compatibility, follow ESD safety procedures, insert the module correctly, and verify fiber connections and port status.Compatibility and Preparation

Before installation, confirm that the Huijue optical module is compatible with your switch or device. Check the module type (e.g., OSFP, QSFP-DD), supported data rate (e.g., 800G), and fiber type (single-mode or multi-mode) to avoid mismatches that can affect performance or damage the module . Only use certified modules for your device to ensure transmission reliability . Wear an ESD wrist strap or gloves to prevent electrostatic discharge, which can damage the module . Keep dust plugs on idle ports and on the module before installation.

Installation Steps
  1. Remove Dust Plugs: Take off the dust plug from the optical port and keep it for future use .
  2. Insert the Module: Align the module with the port and gently insert it. If it does not fit, turn it over and try again . Avoid touching the edge connector.
  3. Connect Optical Fibers: After the module is fully seated, connect the optical fibers. Ensure the fibers match the module type (single-mode to single-mode, multi-mode to multi-mode) and check that the input optical power is within the safe range to prevent damage .
  4. Secure Fiber Connectors: Release the locking clip on the fiber connector, gently push it in, and ensure it is firmly seated. Cover unused connectors with dust caps .
Post-Installation Checks
  • Verify the port status using device commands (e.g., display interface xgigabitethernet0/0/2 for Huawei switches) to ensure the port is not administratively down .
  • Check the wavelength, received, and transmitted optical power to confirm normal operation .
  • Perform a loopback test if necessary to troubleshoot connectivity issues .
Safety Precautions
  • Never look directly into the optical module or fiber ends, as laser radiation can cause eye damage .
  • Avoid excessive force when connecting fibers to prevent damage to the module or connectors . By following these steps and precautions, you can safely add a Huijue optical module and ensure reliable network performance.
