How to convert a gigabit switch into a PoE switch

Fiber optic splice closure knowledge brief Published 28 Nov 2023

Prepared for preliminary research by the RIVO OPTICAL knowledge desk. Confirm cable count, splice capacity, sealing class, tray layout, protection sleeves and installation requirements against current standards and product documentation.

You can convert a standard gigabit switch to a PoE switch using PoE injectors, which supply power alongside data to PoE-enabled devices.Using PoE Injectors

A PoE injector is the most practical way to add PoE functionality to a non-PoE switch. It sits between your switch and the powered device (PD), injecting electrical power into the Ethernet cable while allowing data to pass through. The steps are:

  1. Test all equipment: Ensure your IP cameras, PoE injectors, and network devices are functioning correctly before installation .
  2. Connect the injector to the device: Plug an Ethernet cable from the injector's PoE port to the PoE-enabled device.
  3. Connect the injector to the switch: Use another Ethernet cable to connect the injector's data port to your standard gigabit switch.
  4. Power the injector: Plug the injector into a local AC outlet to supply power to the connected device . This method allows you to power devices up to 100 meters away without modifying the switch hardware.
Considerations and Safety
  • Active vs. Passive PoE: Active PoE switches negotiate power with the device, ensuring only compatible devices receive power. Passive PoE injectors always supply power, which can damage non-PoE devices if connected incorrectly .
  • Device compatibility: Ensure your powered devices support the PoE standard (e.g., IEEE 802.3af or 802.3at) to avoid overloading or underpowering them .
  • Centralized power management: Using PoE injectors or a PoE switch allows centralized control of power, enabling remote resets or shutdowns for maintenance .
Alternative: Upgrading to a PoE Switch

While injectors are cost-effective for a few devices, if you plan to power multiple devices, upgrading to a dedicated PoE switch may be more efficient. PoE switches combine data and power delivery in one device, simplify cabling, and provide better power management and heat dissipation .

Summary
  • PoE injectors are the easiest way to retrofit a standard gigabit switch for PoE devices.
  • Active PoE is safer for mixed networks with non-PoE devices.
  • For larger deployments, consider a dedicated PoE switch for centralized power and simplified management.
  • Always verify device compatibility and power requirements to prevent damage.
